File Integrity Monitor
Description
Integrity in CIA Triad means the correctness in a file. If a data gets changed or edited an alert needs to be triggered so that an analyst or others can check the integrity This projects is to create a FIM – File integrity Monitor powershell script(below). FIM – is to monitor some important files and is designed to provide an alert once it gets modified
# change the file path D:\Desktop\FIM\baseline.txt and D:\Desktop\FIM\Files in the script based on project scenario
# D:\Desktop\FIM\baseline.txt - is the saved baseline file
# D:\Desktop\FIM\Files - folder where the files are stored
Write-Host " "
Write-Host "Please select from the below options"
Write-Host " A) Do you want to collect a new Baseline ?"
Write-Host " B) Do you want to check files with saved baseline?"
Write-Host " "
$response = Read-Host -prompt "Please enter 'A' or 'B'. "
Write-Host " "
Write-Host "You have selected" $response
Write-Host " "
Write-Host " Please wait ... "
Start-Sleep -Seconds 2
# Creating a function to calculate the hash file
Function calc-file-hash($filepath) {
# Function will go to the file path, calculate the hash value and returns it
$Hash = Get-FileHash -Path $filepath -Algorithm SHA512
return $Hash
}
#Creating a function to clear the text file if exists
function file-if-exists(){
$fileexists = Test-Path -Path D:\Desktop\FIM\baseline.txt
if ($fileexists){
#Remove file if exists
Remove-Item -Path D:\Desktop\FIM\baseline.txt
}
}
if ($response -eq "A".ToUpper()){ #Calculate the hash and store it in baseline.txt
file-if-exists #Delete file if exists
$files = Get-ChildItem -Path D:\Desktop\FIM\Files # Collect all the files from the path
foreach ($item in $files) # For each item in files, we calculate the hash and store in Baseline.txt
{
$file_hashes = calc-file-hash $item.FullName
"$($file_hashes.Path)|$($file_hashes.Hash)"| Out-File -FilePath D:\Desktop\FIM\baseline.txt -Append
}
Write-Host " New baseline collected" -ForegroundColor Yellow
}
elseif ($response -eq "B".ToUpper()) {
$hash_dictionary = @{} #Create an empty dictionary
#Add two columns here
#Load hash from baseline.txt and store in a dictionary
$filepath_and_hashes = Get-Content -Path D:\Desktop\FIM\baseline.txt
foreach ($items in $filepath_and_hashes){
#Split the items into two at the | section and it will create an Array, where it stores 0th element to one and 1st element to other
$hash_dictionary.Add($items.Split("|")[0],($items.Split("|")[1]))
}
# While loop to continuously monitor files with the saved baseline
while ($true){
Start-Sleep -Seconds 1
$files = Get-ChildItem -Path D:\Desktop\FIM\Files # Collect all the files from the path
foreach ($item in $files) { # For each item in files, we calculate the hash and store in Baseline.txt
$file_hashes = calc-file-hash $item.FullName
#A file has been created !! Notify
if ($hash_dictionary[$file_hashes.Path] -eq $null) {
Write-Host "$($file_hashes.Path) has been created !!" -ForegroundColor Green
}
else{
#Hashes of file are equal
if ($hash_dictionary[$file_hashes.Path] -eq $file_hashes.Hash){
#Write-Host " $($file_hashes.Path)has not changed "
}
else {
Write-Host "$($file_hashes.Path) has been changed !! " -ForegroundColor Red
}
}
foreach ($key in $hash_dictionary.keys){
$file_exists= Test-Path -Path $key
if (-Not $file_exists){
Write-Host "$($key) has been deleted" -ForegroundColor DarkRed -BackgroundColor white
}
}
}
}
}
else {
Write-Host "Invalid Entry, Please try again"
}
Languages and Utilities Used
- PowerShell - Virtual machine in VMWARE
Environments Used
- Windows 10 (21H2)
Procedure:
- Create a Windows VM Machine in VMware or any virtualisation platform (We can also use primary computer if running a Windos OS )
- Create or provide the path of the files that needs to be checked inside the Script
- Pass the file path for saving or taking the baseline for checking
Script Process Walkthrough:
Start the powershell script in powershell ISE
Ask user what they want to do
A) Collect new baseline
B) Begin monitoring files with saved baseline
Process A
--> Calculate Hash value from Target files (Hash is taking the digital thumbprint of a text file and stores in a text file)
--> Store the file or Hash pairs in Baseline.txt
Process B
--> Load file or Hash pair from the existing Baseline.txt
--> Loop through each target file, calculate the hash and compare the file or hash to baseline.txt
--> Notify user if a file is changed or deleted
--> If a file's actual hash is different than what is recorded in baseline, print in the screen.
--> If a file is deleted, says Integrity Compromised !!!
